Description
Dimensions: 485 x 285.4 x 43.7 mm (19.1 x 11.2 x 1.7")
Port Layout:
- 1 GbE RJ45: 24 (All PoE+) (1G/100M/10M)
- 1G SFP: 2 (1G)
Max. PoE Output: Up to PoE+
Total PoE Availability: 250W
Redundancy: DC Power Backup
Form Factor: Rack mount (1U)
Switching Capacity: 52 Gbps
Total Non-Blocking Throughput: 26 Gbps
Forwarding Rate: 38.69 Mpps
Access Lists: - IPv4: 128
- MAC: 128
LACP Port Aggregation: ✓
STP & RSTP: ✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port): ✓
IGMP Snooping: ✓
802.1X Control: ✓
MAC-Based ACLs & Device Isolation: ✓
DHCP Snooping & Guarding: ✓
Egress Rate Limit: ✓
Flow Control: ✓
Storm Control: ✓
Multicast & Broadcast Rate Limiting: ✓
MAC Address Blocking: ✓
IP-Based ACLs & Network Isolation: ✓
MAC-Based Port Restriction: ✓
Port Isolation: ✓
Port Mirroring: ✓
Jumbo Frames: ✓
LLDP-MED: ✓
Voice VLAN: ✓
Loop Protection: ✓
PoE Ports: - PoE+: 24
Max. PoE Wattage per Port by PSE: - PoE: 17W
- PoE+: 34W
Max. Power Consumption: 30W (Excluding PoE Output)
Power Method: Universal input, 100—240V AC, 50/60 Hz
Power Input Method: AC input
Power Supply: AC/DC, internal, 250W
Supported Voltage Range: 100—240V AC
Management: Ethernet
Weight: 4.7 kg (10.4 lb)
Enclosure Material: SGCC steel
Mount Material: SGCC steel
Supported Rack Depth: 400~1200 mm (15.7-47.2")
ESD Protection: Air/contact: ± 24kV
Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
Ambient Operating Humidity: 5 to 95% noncondensing
LEDs: - Ethernet: ✓
- SFP: ✓
- System: ✓
NDAA Compliant: ✓
Certifications: CE, FCC, IC, Anatel
Application Requirements: UniFi Network Version 6.3.51 and later
Warranty
1 Year
