Description
Dimensions Ø110 x 184.1 mm (Ø4.3 x 7.3")
Weight 1.1 kg (2.4 lb)
Enclosure material Polycarbonate
Hardware
Processor Quad-core Arm® Cortex® A53 at 1.5 GHz
System memory 3 GB DDR4
Expansion slot MicroSD memory card*
64 GB pre-installed microSD.
Management interface Ethernet
Bluetooth
Networking interface LAN:
(3) 2.5 GbE RJ45 ports
WAN:
(1) 10G SFP+ port
(1) 2.5 GbE RJ45 port
PoE interface (1) PoE (Pair A 1, 2+; 3, 6-)
IDS/IPS throughput 2.3 Gbps
Power method Universal AC input, 100—240V AC, 1.5A Max., 50/60 Hz
Power supply AC/DC, internal, 50W
Supported voltage range 100—240V AC
Max. power consumption 26W (Excluding PoE output)
PoE budget 15.4W
Max. PoE wattage per port by PSE 15.4W
Voltage range PoE mode 44—57V DC
Max. TX power
2.4 GHz
5 GHz
6 GHz
23 dBm
26 dBm
24 dBm
MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz
6 GHz
688 Mbps (BW40)
4.3 Gbps (BW240)
5.7 Gbps (BW320)
Antenna gain
2.4 GHz
5 GHz
6 GHz
5 dBi
7 dBi
6 dBi
LCM display (1) 0.96" screen
Button Factory reset
LEDs White/blue
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting
Next-generation security Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced networking License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support
Software
WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID 4 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Application Requirements
UniFi Network Version 9.0.108 and later
Warranty
1 Year
