Description
GPU Engine Specs
- CUDA Core:s 4608
- Boost Clock (MHz): 2602MHz
- Base Clock (MHz): 2235MHz
Thermal & Power Spec
- Minimum System Power Requirement (W): 650W
- Supplementary Power Connectors: 1x PCIe 8-pin cables
Memory Specs
- Memory Clock: 28Gbps
- Standard Memory Config: 16GB
- Memory Interface: GDDR7
- Memory Interface Width:128-bit
- Memory Bandwidth (GB/sec): 448 GB/sec
Feature Support
Real-Time Ray Tracing: Yes
Ray Tracing Cores: 4th Generation, 72 TFLOPS
Tensor Cores: 5th Generation, 759 AI TOPS
NVIDIA Architecture: Blackwell
Microsoft DirectX 12 Ultimate
NVIDIA DLSS 4
NVIDIA Ansel: Yes
NVIDIA FreeStyle: Yes
Bus Support: PCI Express Gen 5
NVIDIA ShadowPlay: Yes
OS Certification: Windows 11 / 10, Linux, FreeBSDx86
NVIDIA Highlights: Yes
NVIDIA G-SYNC™-Ready: Yes
Game Ready Drivers: Yes
NVIDIA Studio Drivers: Yes
NVIDIA GPU Boost™: Yes
Vulkan API 1.4
OpenGL 4.6
NVIDIA Encoder: 1x Ninth Generation
NVIDIA Decoder: 1x Sixth Generation
Accessories
- Graphics Card Dimensions: Length 250mm Height 116mm Width 41mm
- Display Support Multi Monitor: up to 4
- Maxmium Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC
- HDCP 2.3
- Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b
Warranty
3 Years
